How to Mount a TV with 24-Inch Studs – Easy Guide, Tips & More

Popular Category: Tv mounts

Share on facebook
Share on twitter
Share on linkedin

Table of Contents

It can be daunting to mount a TV on a wall. However, in a wall with the studs too far apart, this process can seem even more difficult.

With our easy guide, you’ll be able to mount TVs on walls with 24inch studs in no time.

Remember to use the right tools, quality hardware and follow the instructions step by step. You will have no issue with the mounting process.

Quick summary

In this article we will learn the following things:

  • How to mount a TV with 24-inch wall studs?
  • Tips on how to pick the right TV mount for your wall

Why are Studs too far Apart in some Walls?

studs

In many modern homes, studs are spaced 16-inches apart from center to center. However, in certain walls or building structures, studs can be spaced 24-inches apart as well.

These walls usually are considered to have the studs ‘too far apart’.

This is because many TV VESA patterns will not have mounting holes that reach both studs. This causes issues in installation and can even impact how safely mounted your TV is.

What is the Use of Wall Studs?

Wall studs help give solid foundations to screw in the mounting plate of the TV mount bracket. They are sturdy and can bear more weight than other areas of the wall.

Studs are the most secure area in the wall to make mounting holes for your TV.

How do I find out how far Apart the Studs in my wall are?

To find out where the studs in your wall are and how far apart they are, you will need a stud finder. Take the stud finder and move it across the wall.

Mark the area where the stud finder locates a stud. Now move forward horizontally from that spot until you find another stud.

Measure the distance between the two studs to find out how far apart they are. They will usually be either 16-inches or 24-inches apart.

Tools You Will Need to Mount a TV

tools

To successfully mount a TV on walls with 24-inch studs you will need to use the right tools and quality hardware. Here are some of the things you will need:

  • Drill
  • Mounting bracket
  • Mounting screws
  • Hammer
  • Screwdriver
  • Wall anchors
  • Pencil
  • Level
  • Stud Finder

Easy Guide to Mount a TV with 24-Inch Stud Walls

mount tv

Here is the easy step-by-step guide that will help you mount a TV on the wall with 24-inch studs:

Step 1

The first step is to ensure the walls are in good condition and can withstand the weight of the TV. This will help protect your TV from accidentally falling or damaging the wall.

Make sure to check for cracks or dryness in the wall to ensure its quality.

Step 2

Using a stud finder, mark the locations of the studs and measure the distance from center to center.

Make a midpoint between the two studs and use it for reference as the central point. Apply the VESA pattern from here so that is each screw is equal distance from each stud.

Mark the new holes for the mounting plate and check with a level.

Step 3

drill bits

Using a masonry drill bit or a regular drill, depending on the type of wall, make the holes for the mounting screws.

Make sure the holes are wide enough to incorporate the screws as well as the wall anchors. Do not drill the holes too loose.

Step 4

Add the wall anchors and lock them in place. Make sure that the anchors are secured tightly and will not move once the TV is mounted.

Screw in the mounting screws along with the mounting plate. Tighten screws diagonally to ensure the best installment of the mounting plate.

This will ensure that the tension in each screw is equal.

Step 5

Carefully mount your TV to the installed mounting plate and check for any loose connections. Make sure to manage the wires properly so that they do not get in the way or look messy.

Check to see if the TV is leveled and installed straight.

 In case your TV has tilt or swivel options, make adjustments externally.

Considering the Weight of Your TV

One of the most important things to take into consideration is the weight of the TV.

Since the mounting plates will be installed in between the studs, they will have a pull on the material of the wall. In most cases, people prefer to do on plaster walls with studs

Can a TV be too Heavy for a Wall?

No, TVs cannot be too heavy for a wall but they can be too heavy for a wall mount. This is why the weight of the TV in regards to the mount and the condition of the wall is so stressed upon.

Tips on Picking the Right TV Mount for Your Wall

tv mounts

Here are some tips to ensure you will pick the right TV mount for your wall:

  1. If you do not change the setting of your room often, a simple TV mount is perfect for a 24-inch stud wall.
  2. In case you have multiple viewing angles in the room for a singular TV, a full-motion TV mount would be the best option to choose.
  3. For TVs that are mounted in the corner or higher up near the ceiling, tilt mounts are useful in adjusting the angle.
  4. If you feel your wall is not strong enough to withstand a TV, consider mounting it on a TV stand or ceiling mount instead.
  5. In case you do not wish to drill into your wall, mounting a TV on a rail mount is another option that you can take into consideration.

The Main Takeaway

We have completed our easy guide on ‘how to mount a TV with 24-inch studs’. For a secure installment, make sure to use quality hardware and follow the instructions carefully.

If you feel that you cannot determine the condition of your wall, it is better to have a professional opinion on the matter.

For any further information, feel free to reach out to us.
